The most important questions of the theory of machines, subject to all chapters, are given below.
TOM 313313 IMP Question Bank for MSBTE Summer 2025 Exam
- Define a) Higher pair, b )Lower pair, with one example
- Define: a) Kinematic link, b) Kinematic chain, c) Kinematic pair with example
- State the types of constrained motion. Sketch any one
- Define the following with an example (i)Mechanism, (ii) Machine (iii) Inversion
- Define sliding pair and turning pair with an example
- List any four inversions of the single slider crank chain mechanism
- Define completely constrained motion and successfully constrained motion.
- Explain the crank and slotted lever mechanism with a neat sketch
- State the inversions of a bar chain mechanism and explain any one with a neat sketch
- Give the classification of kinematic pairs. Explain any one
- Explain with a neat sketch the working of the beam engine
- Explain with a neat sketch the working of the Scotch Yoke mechanism
- Explain the working of the Whitworth Quick Return mechanism
- Draw a neat sketch of Oldham’s coupling and explain it.
Conclusion
In this post, we shared the theory of machines and important questions for the upcoming diploma exams.
